Dahua DH-PFS3010-8GT-96 8-Port Gigabit Desktop Switch

Dahua DH-PFS3010-8GT-96 8-Port Gigabit Desktop Switch
Catalogue No:
DH-PFS3010-8GT-96
£94.88
(Exc. 20% VAT)
(£113.86 Inc. VAT)
–
+
Dahua
Information

Dahua DH-PFS3010-8GT-96 8-Port Gigabit Desktop Switch

8-Port Gigabit Desktop Switch

Key Features

  • Intelligent PoE
  • 8-pin assignment PoE power supply
  • Long distance PoE
  • PoE watchdog
  • All-gigabit ports
Specifications
Hardware
Data Transmission Port Port 1–8: 8 × RJ-45 10/100 Mbps (PoE)
Port 9-10: 2 × RJ-45 10/100/1000 Mbps (Uplink)
Power Supply 48 V - 57 V DC
Operaing Temperature –10 °C to +55 °C (+14°F to +131°F)
Operating Humidity 5% – 95% (RH)
Storage Temperature –20 °C to +70 °C (–4°F to +158°F)
Storage Humidity 5% – 95% (RH)
Power Consumption Idling: 3 W
Full load: 96 W
Performance
Capacity 5.60 Gbps
Packet Forwarding Rate 4.17 Mpps
Packet Buffer Memory 4 Mbit
MAC Table Size 8K
Communication Standard IEEE802.3/IEEE802.3u/IEEE 802.3ab/IEEE802.3x
PoE
PoE Standard IEEE802.3af; IEEE802.3at; Hi-PoE; IEEE802.3bt
PoE Power 96 W
Power Consumption Management Yes
PoE Pin Assignment 1, 2, 4, 5 (V+), 3, 6, 7, 8 (V-)
Long Distance PoE 250 m long distance PoE transmission
PoE Watchdog Yes
General
Statics Protection Air discharge: 8 kV
Contact discharge: 6 kV
Thunder-proof Common mode: 4 kV
Differential mode: 2 kV
Net Weight 0.50 kg (1.10 lb)
Gross Weight 1.32 kg (2.91 lb)
Product Dimensions 190 mm × 100 mm × 30 mm (7.48" × 3.94" × 1.18")
Datasheet

Datasheet
Datasheet

Product Attributes
Catalogue No
DH-PFS3010-8GT-96
Brand
Dahua
